Often referred to simply as a chimney hood, this common cooker hood design offers high value for money and looks a treat.
With the main body of the hood being 90cm wide this hood is ideal for 90cm range cookers or 5 zone hobs. If there is space in your kitchen this hood creates a big impression.
Three fan speeds are adjusted from the fascia with push button controls which also control the lighting – a pair of bright LED bulbs.
You can easily remove the two aluminium grease filters for cleaning which also gives access to the motor assembly, which is where the optional charcoal (aka carbon) filters are fitted if you opt to recircle your cooking air instead of ducting out.
TIP: Extracting air through ducting does not require use of a charcoal filter. Optional charcoal filters are used to help remove cooking odours from the air before it is recycled back into the kitchen.
Type: | Chimney Hood |
Width: | 900mm |
Speeds: | 3 Speed |
Control type: | Push Button |
Extraction rate: | 320m3 |
Illumination: | 2 x 3w bulb LED |
Installation Height - Electric Hob: | 65cm minimum |
Installation Height - Gas Hob: | 75cm miminum |
Installation Template: | Supplied |
Cable termination: | 13a UK plug |
Cable length: | 150cm |
Fluid Dynamic Efficience (FDE): | 8.9 |
Fluid Dynamic Efficience Class (FDE): | E |
Light Efficiency (LE): | 15 |
Light Efficiency Class (LE): | D |
Grease Filtering Efficiency (GFE): | 75.9 |
Grease Filtering Efficiency Class (GFE): | C |
Energy Efficiancy Class (EEI): | D |
Duct or Recycle Compatible: | Yes |
Duct: | Ready from factory |
Duct Outlet Diameter: | 120mm round |
Charcoal Filter (optional): | Altimo CF003 |
Quantity Needed Per Change: | 2 required (2 supplied) |
Voltage: | AC220-240v 50hz |
Motor Power: | 125w |
Lamp Power: | 2 x 3w |
Total Power: | 131w |
Annual Energy Consumption (AEC) (kWh/a): | 69.2 |
Minimum Air Flow in normal use (m3/h): | 182 |
Maximum Air Flow in normal use (m3/h): | 291 |
Sound Level at Minimum Speed (dB): | 53 |
Sound Level at Maximum Speed (dB): | 63 |
Power Consumption in off mode (w): | 0 |
